Data cables
3 Welcome to the most extensive products and services portfolio in the market Prysmian Group, a world leader in the energy and telecom cable industry with more than 140 years of experience, is strongly positioned in high-tech markets and offers the widest possible range of products, services, consultancy and know-how in the market. Our extensive customer portfolio, from all market segments, allows us to provide energy, telecommunications products and services in a wide range of applications, such as medium and low voltage cables for the construction and infrastructures sectors, special cables for the strictest industries and underground and submarine systems. In all cases with the highest standards of quality. Since 2018, Prysmian Group has been consolidating its presence in Portugal through its merger with General Cable Celcat, thus strengthening its position as a market leader due to its vast experience, know-how and service availability. In this way, General Cable, together with Prysmian and Draka, have now become part of the family of brands owned by Prysmian Group. We increase the value of the products and technologies that we develop. The result is a complete portfolio of totally exclusive products and services that, along with our proximity, make us a solid and essential ally for customers who strive day by day to be competitive and to grow. Visit our website at: www.prysmiangroup.pt or call us on +351 21 967 85 00.
4 XZ1-Al (S) 0,6/1,0 kV a.c. (1,2/1,2 kV a.c. máx) 1,5/1,5 kV d.c. (1,8/1,8 kV d.c. máx) Cable Type Category Class Page U/UTP CAT5E 4PR LSZH U/UTP 5E Cca 6 U/UTP CAT5E 4PR LSZH/PVC U/UTP 5E Dca/Eca 7 U/UTP CAT5E 4PR PVC + PE U/UTP 5E Fca 8 U/UTP CAT5E 4PR PE U/UTP 5E Fca 9 U/UTP CAT5E 4PR PVC + ARMOUR + PE U/UTP 5E Fca 10 U/UTP CAT5E 2x4PR LSZH/PVC U/UTP 5E Dca/Eca 11 F/UTP CAT5E 4PR LSZH F/UTP 5E Cca 14 F/UTP CAT5E 4PR LSZH/PVC F/UTP 5E Dca/Eca 15 F/UTP CAT5E 4PR PVC + ARMOUR + PE F/UTP 5E Fca 16 F/UTP CAT5E 2x4PR PVC F/UTP 5E Eca 17 U/UTP CAT6 HD 4PR LSZH U/UTP 6 Cca 20 U/UTP CAT6 4PR LSZH/PVC U/UTP 6 Dca/Eca 21 U/UTP CAT6 HD 4PR PVC + PE U/UTP 6 Fca 22 U/UTP CAT6 HD 4PR PE U/UTP 6 Fca 23 U/UTP CAT6 4PR PVC + ARMOUR + PE U/UTP 6 Fca 24 F/UTP CAT6 4PR LSZH F/UTP 6 Cca 26 F/UTP HD CAT6 4PR LSZH/PVC F/UTP 6 Dca/Eca 27 F/UTP HD CAT6 4PR PVC + PE F/UTP 6 Fca 28 F/UTP HD CAT6 4PR PE F/UTP 6 Fca 29 F/UTP CAT6 4PR PVC + ARMOUR + PE F/UTP 6 Fca 30 U/UTP CAT6A E1 4PR LSZH U/UTP 6A Cca 32 U/UTP CAT6A E1 4PR LSZH U/UTP 6A Dca 33 F/UTP CAT6A 4PR LSZH/PVC F/UTP 6A Dca/Eca 36 U/FTP CAT6A 4PR LSZH U/FTP 6A Dca 38 F/FTP CAT6A 4PR LSZH F/FTP 6A Dca 40 U/UTP CAT5E 25PR LSZH/PVC U/UTP 5E Multipar Dca/Eca 42 F/UTP CAT5E 25PR LSZH/PVC F/UTP 5E Multipar Eca 44 Cable index
5 Type U/UTP Category 5E
6 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Cca-s1,d2,a1 (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Green [GN] - Cca PART NUMBER/PACKAGING Cca: 60094718 / Box 305m [GN] Cca: 60094717 / Reels 500m [GN] Cca: 60094716 / Reels 1000m [GN] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Sheath: LSZH material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 4PR LSZH Cca Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Cca 5,6 39,5 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC.
7 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Dca-s2,d2,a1 Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • White [WH] - Dca • Grey [GY] - Eca PART NUMBER/PACKAGING Dca: 60080858 / Box 305m [WH] Dca: 60080856 / Reels 500m [WH] Dca: 60080857 / Reels 1000m [WH] Eca: 60080844 / Box 305m [GY] Eca: 60080842 / Reels 500m [GY] Eca: 60080843 / Reels 1000m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Sheath: LSZH material (for Euroclass Dca cable) 4 – Sheath: PVC material (for Euroclass Eca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 4PR LSZH U/UTP CAT5E 4PR PVC Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Dca 5,1 31,0 Eca 5,5 30,5 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca Dca
8 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60099120 / Reels 500m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Outer sheath: PVC material 5 – Outer sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 4PR PVC + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 6,5 44,0 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca
9 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60080868 / Reels 500m [BK] Fca: 60080871 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Outer sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 4PR PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 5,4 29,0 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca
10 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60081015 / Reels 500m [BK] Fca: 60081016 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Inner Sheath: PVC material 5 – Armour: Corrugated Aluminium Tape (CATA) 6 – Outer sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 85 • @100-1000MHz 85-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 4PR PVC + ARMOUR + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 11,4 135,0 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca
11 STANDARDS IEC 61156-5 EN 50288-3-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Dca-s2,d2,a1 Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • White [WH] - Dca • Grey [GY] - Eca PART NUMBER/PACKAGING Dca: 60080865 / Reels 500m [WH] Dca: 60080866 / Reels 1000m [WH] Eca: 60080853 / Reels 500m [GY] Eca: 60080854 / Reels 1000m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Sheath: LSZH material (for Euroclass Dca cable) 4 – Sheath: PVC material (for Euroclass Eca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT5E 2x4PR LSZH U/UTP CAT5E 2x4PR PVC Not at scale Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca Dca EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Dca 5,2 x 10,8 65,0 Eca 5,0 x 10,4 61,5
13 Type F/UTP Category 5E
14 STANDARDS IEC 61156-5 EN 50288-2-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Cca-s1,d1,a1 (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Green [GN] - Cca PART NUMBER/PACKAGING Cca: 60094799 / Box 305m [GN] Cca: 60094315 / Reels 500m [GN] Cca: 60094314 / Reels 1000m [GN] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Drain wire: Tinned Copper conductor 5 – Shield: Aluminium/Polyester 6 – Sheath: LSZH material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP CAT5E 4PR LSZH Cca Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Cca 6,0 40,5 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC.
15 STANDARDS IEC 61156-5 EN 50288-2-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Dca-s2,d2,a1 Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • White [WH] - Dca • Grey [GY] - Eca PART NUMBER/PACKAGING Dca: 60080882 / Box 305m [WH] Dca: 60080880 / Reels 500m [WH] Dca: 60080881 / Reels 1000m [WH] Eca: 60080876 / Box 305m [GY] Eca: 60080874 / Reels 500m [GY] Eca: 60080875 / Reels 1000m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Drain wire: Tinned Copper conductor 5 – Shield: Aluminium/Polyester 6 – Sheath: LSZH material (for Euroclass Dca cable) 6 – Sheath: PVC material (for Euroclass Eca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP CAT5E 4PR LSZH F/UTP CAT5E 4PR PVC Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Dca 5,7 37,0 Eca 5,6 36,5 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca Dca
16 STANDARDS IEC 61156-5 EN 50288-2-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60082881 / Reels 500m [BK] Fca: 60080891 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… F/UTP CAT5E 4PR PVC + ARMOUR + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 11,5 130,6 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Drain wire: Tinned Copper conductor 5 – Shield: Aluminium/Polyester 6 – Inner sheath: PVC material 7 – Armour: Corrugated Aluminium Tape (CATA) 8 – Outer sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 85 • @100-1000MHz 85-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter
17 STANDARDS IEC 61156-5 EN 50288-2-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) REACTION TO FIRE Class: Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Grey [GY] - Eca PART NUMBER/PACKAGING Eca: 60080879 / Reels 500m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 24 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Drain wire: Tinned Copper conductor 5 – Shield: Aluminium/Polyester 6 – Sheath: LSZH material (for Euroclass Dca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP CAT5E 2x4PR PVC Not at scale Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 65,3 62,3 64,0 61,0 63,2 60,2 20,0 4 4,1 56,3 53,3 52,0 49,0 52,2 49,2 23,0 10 6,5 50,3 47,3 44,0 41,0 43,8 40,8 25,0 16 8,3 47,2 44,2 39,9 36,9 39,0 36,0 25,0 20 9,3 45,8 42,8 38,0 35,0 36,5 33,5 25,0 31,25 11,7 42,9 39,9 34,1 31,1 31,1 28,1 23,6 62,5 17,0 38,4 35,4 28,1 25,1 21,4 18,4 21,5 100 22,0 35,3 32,3 24,0 21,0 13,3 10,3 20,1 125 24,9 33,8 30,8 22,1 19,1 9,0 6,0 19,4 200* 32,4 30,8 27,8 18,0 15,0 --- --- 18,0 250* 36,9 29,3 26,3 16,0 13,0 --- --- 17,3 300* 41,0 28,1 25,1 14,5 11,5 --- --- 16,8 500* 55,5 24,8 21,8 10,0 7,0 --- --- 15,2 600* 62,0 23,6 20,6 8,4 5,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Eca 5,7 x 11,8 75,5
19 Type U/UTP Category 6
20 STANDARDS IEC 61156-5 EN 50288-6-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Cca-s1,d1,a1 (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Green [GN] - Cca PART NUMBER/PACKAGING Cca: 60094814 / Box 305m [GN] Cca: 60093574 / Reels 500m [GN] Cca: 60094316 / Reels 1000m [GN] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross filler 5 – Sheath: LSZH material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 101 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT6 HD 4PR LSZH Cca Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Cca 5,7 40,5 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC.
21 STANDARDS IEC 61156-5 EN 50288-6-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM REACTION TO FIRE Class: Dca-s2,d2,a1 Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • White [WH] - Dca • Violet [VT] - Dca • Grey [GY] - Eca PART NUMBER/PACKAGING Dca: 60087919 / Box 305m [WH] Dca: 60087917 / Reels 500m [WH] Dca: 60087918 / Reels 1000m [WH] Dca: 60097857 / Box 305m [VT] Dca: 60097858 / Reels 1000m [VT] Eca: 60087916 / Box 305m [GY] Eca: 60087914 / Reels 500m [GY] Eca: 60087915 / Reels 1000m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross Filler 5 – Sheath: LSZH material (for Euroclass Dca cable) 5 – Sheath: PVC material (for Euroclass Eca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 101 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT6 4PR LSZH U/UTP CAT6 4PR PVC Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Dca 5,5 36,0 Eca 5,5 36,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca Dca Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7
22 STANDARDS IEC 61156-5 EN 50288-6-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60099208 / Reels 500m [BK] Fca: 60099206 / Reels 1000m [BK] Fca: 60099207 / Wooden Drum 5000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross Filler 5 – Inner Sheath: PVC material 6 – Outer Sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT6 HD 4PR PVC + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 7,0 50,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7
23 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7 STANDARDS IEC 61156-5 EN 50288-6-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60093486 / Reels 500m [BK] Fca: 60093487 / Reels 1000m [BK] Fca: 60095623 / Wooden Drum 5000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross Filler 5 – Outer Sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 40 • @100-1000MHz 40-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT6 HD 4PR PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 6,0 34,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca
24 STANDARDS IEC 61156-5 EN 50288-6-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60080910 / Reels 500m [BK] Fca: 60080912 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross filler 5 – Inner sheath: PVC material 6 – Armour: Corrugated Aluminium Tape (CATA) 7 – Outer sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 93,8 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Atenuação de acoplamento dB (min.): • @30-100MHz 85 • @100-1000MHz 85-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter U/UTP CAT6 4PR PVC + ARMOUR + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 11,5 126,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7
25 Type F/UTP Category 6
26 STANDARDS IEC 61156-5 EN 50288-5-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Cca-s1,d1,a1 (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Green [GN] - Cca PART NUMBER/PACKAGING Cca: 60092565 / Reels 500m [GN] Cca: 60094317 / Reels 1000m [GN] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross filler 5 – Shield: Aluminium/Polyester 6 – Drain wire: Tinned Copper conductor 7 – Sheath: LSZH material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP CAT6 4PR LSZH Cca Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Cca 7,5 49,0 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC.
27 STANDARDS IEC 61156-5 EN 50288-5-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM REACTION TO FIRE Class: Dca-s2,d2,a1 Eca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • White [WH] - Dca • Grey [GY] - Eca PART NUMBER/PACKAGING Dca: 60090501 / Reels 500m [WH] Dca: 60097720 / Reels 1000m [WH] Eca: 60080915 / Reels 500m [GY] Eca: 60080916 / Reels 1000m [GY] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross Filler 5 – Shield: Aluminium/Polyester 6 – Drain wire: Tinned Copper conductor 7 – Sheath: LSZH material (for Euroclass Dca cable) 7 – Sheath: PVC material (for Euroclass Eca cable) ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP HD CAT6 4PR LSZH F/UTP HD CAT6 4PR PVC Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Dca 7,0 46,5 Eca 7,0 47,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Eca Dca Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7
28 STANDARDS IEC 61156-5 EN 50288-5-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60086852 / Reels 500m [BK] Fca: 60080930 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross filler 5 – Shield: Aluminium/Polyester 6 – Drain wire: Tinned Copper conductor 7 – Inner Sheath: PVC material 8 – Outer Sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 72 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP HD CAT6 4PR PVC + PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 8,5 64,0 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7
29 Freq MHz IL dB/100m (max.) NEXT dB (min.) PSNEXT dB (min.) ELFEXT (ACR-F) dB/100m (min.) PS-ELFEXT (PSACR-F) dB/100m (min.) ACR (dB/100m) (min.) PS-ACR dB/100m (min.) RL dB/100m (min.) 1* 2,1 75,3 72,3 68,0 65,0 73,2 70,2 20,0 4 3,8 66,3 63,3 56,0 53,0 62,4 59,4 23,0 10 6,0 60,3 57,3 48,0 45,0 54,3 51,3 25,0 16 7,6 57,2 54,2 43,9 40,9 49,6 46,6 25,0 20 8,5 55,8 52,8 42,0 39,0 47,3 44,3 25,0 31,25 10,7 52,9 49,9 38,1 35,1 42,1 39,1 23,6 62,5 15,5 48,4 45,4 32,1 29,1 32,9 29,9 21,5 100 19,9 45,3 42,3 28,0 25,0 25,4 22,4 20,1 125 22,5 43,8 40,8 26,1 23,1 21,4 18,4 19,4 200 29,1 40,8 37,8 22,0 19,0 11,6 8,6 18,0 250 33,0 39,3 36,3 20,0 17,0 6,3 3,3 17,3 300* 36,6 38,1 35,1 18,5 15,5 1,5 --- 16,8 500* 49,2 34,8 31,8 14,0 11,0 --- --- 15,2 600* 54,7 33,6 30,6 12,4 9,4 --- --- 14,7 STANDARDS IEC 61156-5 EN 50288-5-1 EN 50173 ISO/IEC 11801 EN 50575 EN 50399 EN 13501-6 APPLICATIONS 10BASE-T (IEEE 802.3) 4/16 Mbps TOKEN RING (IEEE 802.5) 100BASE-VG-AnyLAN 100 Mbps TP-PMD (ANSI X3T9.5) 100BASE-T (IEEE 802.3) 55/155 Mbps ATM 1000BASE-T (Gigabit Ethernet) 1.2 Gbps ATM 10G BASE-T (Length<50m) REACTION TO FIRE Class: Fca (according to EN 13501-6) COLOUR CODES Pairs Colours 1 White-Blue / Blue 2 White-Orange / Orange 3 White-Green / Green 4 White-Brown / Brown Outer sheath colour: • Black [BK] - Fca PART NUMBER/PACKAGING Fca: 60099032 / Reels 500m [BK] Fca: 60099033 / Reels 1000m [BK] OTHER CHARACTERISTICS Storage Temperature -20ºC to 70ºC Operating Temperature -20ºC to 70ºC Laying Temperature -5ºC to +5ºC (recommendation: between -5ºC and +5ºC, prior storage 24h at 20ºC) Note: DATA cables are not suitable for low impedance applications as: heating, lighting, etc… CONSTRUCTION 1 – Conductor: 23 AWG, Solid Bare Annealed Copper 2 – Insulation: Polyolefin 3 – Formation: Varying short pair lay-length (4 pairs) 4 – Cross Filler 5 – Shield: Aluminium/Polyester 6 – Drain wire: Tinned Copper conductor 7 – Outher Sheath: PE material ELECTRICAL AND DIMENSIONAL CHARACTERISTICS Max. dc resistance (Ω/km) @20ºC: 95,0 Nom. mutual capacity (nF/km) @1kHz: 56 NVP (% of light speed): 65 Mean input impedance (Ω): 100 ± 5 @ 100MHz Propagation delay (ns@10MHz): max. 518 Delay skew (ns/100m): max. 40 Coupling Att dB (min.): • @30-100MHz 55 • @100-1000MHz 55-20log(f/100) Max. pulling tension (N): 80 Min. bending radius: 4x outer diameter F/UTP HD CAT6 4PR PE Not at scale EuroClass Approx. outer diameter (mm) Approx. weight (kg/km) Fca 7,5 43,5 TRANSMISSION CHARACTERISTICS * For information only. Note: Insertion loss values for 20ºC. Fca
